Features & Benefits:

All models feature Scroll® compressors for maximum efficiency and quiet operation. 5 Ton RGEA15 models feature UltraTech™ Scroll 2-Stage compressors with Comfort Alert™ diagnostics (see below), high/low pressure switches, and hard start kits.

Louvered condenser compartment for protecting the coil against yard hazards and/or weather extremes

One-piece top with a deep flange to help keep water out of the unit

Supply and return air openings feature a one-inch tall flange to prevent water migration into the ductwork

Access panels have “weep holes” and channels to further help manage water run-off

Side and down discharge options available on all models. All models are shipped ready for horizontal application

Easily accessible blower section complete with slide-out blower

Refrigerant connections are conveniently located for easy service diagnostics

Micro Channel evaporator and condenser delivers superior performance with less refrigerant charge and less weight than conventional copper tube/aluminum fin coils. In addition the all aluminum construction has superior protection against formicary corrosion and aluminum tube rubbing potential. Its easier to clean and has a more robust surface.

 Inside the easily accessible furnace compartment is the draft inducer motor. This motor is specially designed for quiet reliable operation. In addition to the draft inducer motor, the in-shot gas burners and manifold efficiently regulate the flow of gas for combustion. These new gas/electric units also feature direct-spark ignition and remote flame sensors for added reliability and efficiency.

All units feature an internal trap on the condensate line eliminating the need for installing an on-site external trap

Easily accessible control box

Single point wiring simplifies installation

Our gas/electric package units feature a tubular heat exchanger design. Tubular heat exchangers are more efficient and durable than older-style clamshell heat exchangers. The heat exchanger is backed by a 10 year limited warranty. Models with a stainless steel heat exchanger installed in a residential application are backed by a limited lifetime warranty.

Thermal expansion valve standard on all models for superior superheat control, reliability, and energy efficiency at all operating conditions.

Filter drier standard on all models (not shown)

Rugged baserail included for improved installation and handling

Complete factory charged, wired and run tested

Molded compressor plugs

A double-sloped evaporator coil drain pan assures all water is removed from the unit to improve indoor air quality
