Features:

EcoNet™ Enabled product - The EcoNet Smart Home System provides advanced air and water control for maximum energy savings and ideal comfort [1]

Energy Efficiency - Feature 17-SEER cooling rating across all capacities [2]

Copeland Scroll™ variable speed compressor - This inverter driven compressor provides three stages of heating and cooling operation for maximum comfort and energy savings. The overdrive feature in heating provides heating down to 7°F

Equipped with electronic expansion valve to precisely control variable refrigerant flow

New composite base pan – dampens sound, captures louver panels, eliminates corrosion and reduces number of fasteners needed

Improved tubing design – reduces vibration and stress, making unit quieter and reducing opportunity for leaks

Optimized defrost characteristics - decrease defrosting and provide better home comfort

Powder coat paint system – for a long lasting professional finish

Optimized reversing valve sizing – improves shifting performance for quieter unit operation and increased life of the system

Enhanced mufflers – help to dissipate vibration energy for quieter unit operation

Modern cabinet aesthetics – increased curb appeal with visually appealing design

 Curved louver panels – provide ultimate coil protection, enhance cabinet strength, and increased cabinet rigidity

Optimized fan orifice – optimizes airflow and reduces unit sound

Rust resistant screws – confirmed through 1500-hour salt spray testing

PlusOne™ Expanded Valve Space – 3"-4"-5" service valve space – provides a minimum working area of 27-square inches for easier access

Integrated heat pump lift receptacle – allows standard CPVC stands to be inserted into the base

PlusOne™ Triple Service Access – 15" wide, industry leading corner service access – makes repairs easier and faster. The two fastener removable corner allows optimal access to internal unit components. Individual louver panels come out once fastener is removed, for faster coil cleaning and easier cabinet reassembly

Diagnostic service window with two-fastener opening – provides access to the TXV valves and the heat pump reversing valve before opening the unit

External gauge port access – allows easy connection of “low-loss” gauge ports

Single-row condenser coil – makes unit lighter and allows thorough coil cleaning to maintain “out of the box” performance

35% fewer cabinet fasteners and fastener-free base – allow for faster access to internal components and hassle-free panel removal

Service trays – hold fasteners or caps during service calls

QR code – provides technical information on demand for faster service calls

Fan motor harness with extra-long wires – allows unit top to be removed without disconnecting fan wire[1] Purchase and installation of EcoNet WiFi Kit and EcoNet Control Center required. WiFi broadband Internet connection required. Must be paired with EcoNet Enabled furnace or air handler

[2] Refers to the full range of 2-, 3-, 4- and 5-ton capacity Classic Plus™ Series Three-Stage Heat Pumps offered by Rheem.
